Inverter + ESS
Hybrid Inverter + Battery ESS
Hybrid Inverter + Battery ESS
3.2kW / 6.2kW inverter + 16kWh battery
Off-grid high frequency inverter:
The inverter adopts MCU microprocessor full digital SPWM control technology and pure sine wave output.
High efficiency, low noise, environmental protection and energy saving.
Built-in solar charge controller with wide voltage range and ultra-high current performance.
16kWh LiFePO4 battery:
Safe & Durable: LiFePO4 cells, long cycle life and high stability.
IP54 Waterproof: IP54 protection grade, suitable for more installafion soenarios.
 |
 |
 |
| Modular Structure For
Easy Installation. |
Long Cycle Life. | Intelligent Battery Management System. |
 |
 |
 |
| Display Power, Voltage, Charge And Discharge Power | Excellent Safety Features. | Supports Multiple Communication Protocols. |
PRODUCT PARAMETERS
| Battery Parameter | |||||||
| Model | CON-BAT 16kWh | ||||||
| Battery type | LiFePO4 | ||||||
| Nominal capacity | 16076.8Wh | ||||||
| IP Waterproof level | IP54 | ||||||
| Nominal voltage | 51.2V | ||||||
| Limited charge voltage | 58.4V | ||||||
| Discharge cut-off voltage | 40V | ||||||
| Rated charging current | 150A | ||||||
| Max.charge current | 200A | ||||||
| Rated discharge current | 200A | ||||||
| Max. discharge current | 225A | ||||||
| Atmospheric pressure and Relative humidity | 86~106kPa/15%~90%RH | ||||||
| Operate temperature | Charge:0°C~55°C; Discharge:-20°C~75°C; Storage:25°C±2 | ||||||
| Size（L*W*D） | 460*260*940mm | ||||||
| Weight（KG） | 128kg | ||||||
| Inverter Parameter | |||||||
| Model | CON-INV3kW | CON-INV6kW | |||||
| AC Main Grid mode | |||||||
| Rated AC input voltage / waveform | 230Vac / sine wave (mains or generator) | ||||||
| Max. Input voltage range | 170Vac~280Vac (UPS) | ||||||
| Max. AC input voltage | 300Vac | ||||||
| Rated input frequency | 50Hz/60Hz (auto-adaptive) | ||||||
| AC input frequency range | 40-65±1Hz(>42or<63+1Hz inverter mode returns to mains mode) | ||||||
| Max. bypass overload current | 50A | ||||||
| Conversion time | 10ms typical value (UPS); 20ms typical value (home use) | ||||||
| Inverter mode | |||||||
| Rated output power | 3kVA / 3kW | 6kVA / 6kW | |||||
| Works without battery / BMS activation function | Include | ||||||
| Rated output power | Include | ||||||
| Output port number | 2 | 2 | |||||
| Dry node function | Include | ||||||
| Output voltage waveform | pure sine wave | ||||||
| Rated output voltage | 220/230/240 Vac ±5% | ||||||
| Rated output frequency | 50Hz/60HZ ±1Hz | ||||||
| Peak efficiency | 94% | ||||||
| Surge capability | 2 times rated power, 5 seconds protection | ||||||
| Rated battery input voltage | 24Vdc / 48Vdc | 48Vdc | |||||
| Cold start voltage | 23.0Vdc / 46.0Vdc | 46.0Vdc | |||||
| Battery undervoltage protection point | 21Vdc / 42Vdc | 42Vdc | |||||
| Battery overvoltage protection point | 33Vdc / 63Vdc | 63Vdc | |||||
| No-load loss | ＜30W @24Vdc / <45W @48Vdc | <45W @48Vdc | |||||
| AC Main Grid mode charging mode | |||||||
| Max. AC charging current | 80A / 100A(@VI/P=230Vac) | 100A(@VI/P=230Vac) | |||||
| Max. PV charging current | 80A / 120A | 120A | |||||
| Max. Total charging current | 80A / 120A | 120A | |||||
| Charging logic | 3-Step | ||||||
| Constant voltage Flooded Battery Charging voltage Sealed Gel Battery |
29.2Vdc / 58.4Vdc 28.2Vdc / 56.4Vdc |
58.4Vdc 56.4Vdc |
|||||
| Charging voltage of the flooded Battery | 54Vdc | ||||||
| Solar MPPT input | |||||||
| Number of independent MPPT trackers | 1 | ||||||
| Max. power generation of solar energy | 4000W | 6000W | |||||
| Solar MPPT voltage range | 30~450Vdc / 60~450Vdc | 60~450Vdc | |||||
| Solar panel max. open circuit voltage | 500Vdc | ||||||
| Communications | |||||||
| BMS Communication | RS485 protocol | ||||||
| WiFi / APP | RJ45 interface module, optional | ||||||
| Other information | |||||||
| Operating temperature range | -10°C-50°C | ||||||
| Storage temperature | -15°C-60°C | ||||||
| Humidity | 5%-95% relative humidity (no condensation) | ||||||
| Protection grade | IP21 | ||||||
| Size (L*W*D) | 110*311*367mm | 119*335*440mm | |||||
| Net weight (KG) | 7.3kg | 10kg | |||||
1: Test conditions: 25 °C, 100 % depth of discharge (DOD), 1C charge & 1.5C discharge.
2: Refer to battery warranty letter for contitional application.
